Description

The pressure-bearing and pressure-controlling parts are made from forged, the chamber of body appear the oval on the longitudinal section of vertical piston rod. Use ram to open and close by the hydraulic cylinder drive the piston rod. The movement of bonnet is linear type, the movement of bonnet is controlled by two hydraulic cylinder, it is designed the auto sand-cleaning structure on the body. On the intermediate flange, design the secondary seal unit, under the emergency case, if it is observed the fluid flow out by viewport, it can inject the grease urgently.  The type U BOPs have sold to North America, South Asia and got good quality feedback.

ize specification
9″ 3000psi Double Ram BOP Bore:9″
Working pressure: 3000psi
Top connection: 9″ 3000psi 6B R49 Cra Studded
Bottom connection: 9″ 3000psi 6B R49 CRA Flanged
9″ 3000psi Single Ram BOP Bore: 9″
working pressure:3000psi
Top connection: 9″ 3000psi 6B R49 CRA Studded
Bottom connection: 9″ 3000psi 6B R49 CRA Flanged
9″ 5000psi Double Ram BOP Bore:9″
Working pressure: 5000psi
Top connection: 9″ 5000psi 6B R50 CRA Studded
Bottom connection: 9″ 5000psi 6B R50 CRA Flanged
9″ 5000psi Single Ram BOP Bore: 9″
Working pressure: 5000psi
Top connection: 9″ 5000psi 6B R50 CRA Studded
Bottom connection: 9″ 5000psi 6B R50 CRA Flanged
9″ 10000psi Double ram BOP Bore:9″
Working pressure: 10000psi
Top connection: 9″ 10000psi 6B * B*157 CRA Studded
Bottom connection: 9″ 10000psi 6B* B * 157CRA Flanged
9″ 10000psi Single Ram BOP Bore: 9″
Working pressure: 10000psi
Top connection: 9″ 10000psi 6B*B*157CRA Studded
Bottom connection: 9″ 10000psi 6B* B*157 CRA Flanged
11″ 3000psi Double Ram BOP Bore:11″
Working pressure: 3000psi
Top connection: 11″ 3000psi 6B R53 CRA Studded
Bottom connection: 11″ 3000psi 6B R53 CRA Studded
11″3000psi Single Ram BOP Bore: 11″
Working pressure: 3000psi
Top connection: 11″ 3000psi 6B R53 CRA Studded
Bottom connection: 11″ 3000psi 6B R53 CRA Flanged
11″ 5000psi Double ram BOP Bore: 11″
Working pressure:5000psi
Top connection: 11″ 5000psi 6B R54 CRA Studded
Bottom connection: 11″ 5000psi 6B R54 CRA Flanged
11″ 5000psi Single ram BOP Bore: 11″
Working pressure: 5000psi
Top connection: 11″ 5000psi 6B R54 CRA Studded
Bottom connection: 11″
11″ 10000psi double ram BOP Bore:11″
Working pressure: 10000psi
Top connection: 11″ 10000psi 6B *B *158CRA Studded
Bottom connection: 11″ 10000psi 6B*B*158CRA Flanged
11″ 10000psi Singled Ram BOP Bore: 11″
Working pressure: 10000psi
Top connection: 11″ 10000psi 6B*B*158CRA Studded
Bottom connection: 11″ 10000psi 6B*B*158CRA Flanged
13 5/8″ 3000psi Double Ram BOP Bore: 13 5/8″
working pressure: 3000psi
Top connection: 13 5/8″ 3000 psi 6B R57 CRA Studded
Bottom connection: 13 5/8″ 3000psi 6B R57 CRA Flanged
13 5/8″ 3000psi Single ram BOP Bore: 13 5/8″
working pressure: 3000psi
Top connection: 13 5/8″ 3000psi 6B R57 CRA Studded
Bottom connection: 13 5/8″ 3000psi 6B R57 CRA Flanged
13 5/8″ 5000psi Double ram BOP Bore: 13 5/8″
Working pressure: 5000psi
Top connection: 13 5/8″ 5000psi 6B* B * 160CRA Studded
Bottom connection: 13 5/8″ 5000psi 6B*B*160CRA Flanged
13 5/8″ 5000psi single ram BOP Bore: 13 5/8″
Working pressure: 5000psi
Top connection: 13 5/8″ 5000psi 6B*B*160CRA Studded
Bottom connection: 13 5/8″ 5000psi 6B*B*160CRA Flanged
13 5/8″ 10000psi double ram BOP Bore: 13 5/8″
Working pressure: 10000psi
Top connection: 13 5/8″ 10000psi 6B*B*159CRA Studded
Bottom connection: 13 5/8″ 10000psi 6B*B*159CRA Flanged
13 5/8″ 10000psi single ram BOP Bore: 13 5/8″
Working pressure: 10000psi
Top connection: 13 5/8″ 10000psi 6B *B*159CRA Studded
Bottom connection: 13 5/8″ 10000psi 6B*
20 3/4″ 3000psi double ram BOP Bore: 20 3/4″
Working pressure:3000psi
Top connection: 20 3/4″ 3000psi 6B R74 CRA Studded
Bottom connection: 20 3/4″ 3000psi 6B R74 CRA Flanged
20 3/4″ 3000psi single ram BOP Bore: 20 3/4″
working pressure: 3000psi
Top connection: 20 3/4″ 3000psi 6B R74 CRA Studded
Bottom connection: 20 3/4″ 3000psi 6B R74 CRA Flanged
