Description

6/4E-AH Slurry Pump Parts End Cover E024E62

Slurry pump end cover which is installed on both ends of bearing housing to adjust the gaps in bearing assembly. And the end cover can effectively prevent dirt such as ore pulp from entering the bearing, ensuring the safe operation of the bearing and having a longer work-life. End Covers are normally made in grey iron material, ductile iron and steel are also available.

No. Pump Parts Pump Model Parts Code Matl. Code Unit Weight
(kg)
1 Adjust Screw 6/4E-AH E001 E62
2 Base 6/4E-AH E003 G01 143.0
3 Bearing Assembly 6/4E-AH E005M ZWZ Bearing 113.0
4 Bearing Housing 6/4E-AH E004M G01 43.5
5 Cover Plate 6/4E-AH E4013 D21 90.0
6 Cover Plate Bolt 6/4E-AH E4015 E65
7 Cover Plate Liner 6/4E-AH E4018 R55 10.0
8 Cover Plate Liner 6/4E-AH E4018TL1 R55 10.0
9 Discharge Joint 6/4E-AH E4132L S01 0.4
10 End Cover 6/4E-AH E024 G01 3.3
11 Expeller 6/4E-AH E028 A05 7.3
12 Expeller Ring 6/4E-AH E029 A05 15.2
13 Expeller Ring 6/4E-AH E029R R55 4.5
14 Frame Plate 6/4E-AH E4032 D21 106.0
15 Frame Plate Bolt 6/4E-AH DAM026 E62
16 Frame Plate Liner 6/4E-AH E4036 R55 17.0
17 Frame Plate Liner 6/4E-AH E4036TL1 R55 17.0
18 Frame Plate Liner Insert 6/4E-AH E4041 A05 29.0
19 Frame Plate Stud 6/4E-AH D039 E62
20 Gland 6/4E-AH E044 G01 2.6
21 Gland 6/4E-AH E044 C23
22 Gland Bolt 6/4E-AH E045 C23
23 Grease Retainer 6/4E-AH E046 G01 1.9
24 Impeller 6/4E-AH E4147 A05 68.0
25 Impeller 6/4E-AH E4147 R55 23.3
26 Intake Joint 6/4E-AH E4060 S01 0.5
27 Labyrinth 6/4E-AH E062 G01 2.0
28 Labyrinth Locknut 6/4E-AH E061 E62 0.6
29 Lantern Restrictor 6/4E-AH E118 C23 1.0
30 Lantern Ring 6/4E-AH E063 C23 0.6
31 Neck Ring 6/4E-AH E067 C23 0.2
32 O ring 6/4E-AH E109 S10
33 O ring 6/4E-AH F064 S10
34 Packing 6/4E-AH E111 Q05
35 Packing 6/4E-AH E111 Q05A
36 Packing 6/4E-AH E111 Q21
37 Packing 6/4E-AH E111 X06
38 Piston Ring 6/4E-AH E108 G01
39 Seal 6/4E-AH E122 S01 0.4
40 Shaft 6/4E-AH E073M E05 41.6
41 Shaft Sleeve 6/4E-AH E075 C21 2.0
42 Shaft Sleeve 6/4E-AH E075 C23 2.0
43 Shaft Sleeve 6/4E-AH E075 J05
44 Shaft Sleeve 6/4E-AH E076 C21 2.0
45 Shaft Sleeve 6/4E-AH E076 C23 2.0
46 Shaft Sleeve 6/4E-AH E076 J05
47 Shaft Spacer 6/4E-AH E117 C21 1.2
48 Shaft Spacer 6/4E-AH E117 C23
49 Shaft Spacer 6/4E-AH E117 J05
50 Shim Set 6/4E-AH E025 P10
51 Stuffing Box 6/4E-AH E078 A05 15.6
52 Throatbush 6/4E-AH E4083 A05 46.0
53 Throatbush 6/4E-AH E4083 R55 17.4
54 Volute Frame Seal 6/4E-AH E4124 S01 0.6
55 Volute Liner 6/4E-AH E4110 A05 97.0
