Description

◆ Explosion protection to EN,IEC

◆ Can be used in Zone 1,2,21,22 Class I, Zone 1,2  Division 2, Groups A, B, C, D

◆ Three enclosure types: 90, 160, 240

◆ Applicable lamp and power (max.240W)

LED: 60W, 90W, 120W, 160W, 200W, 240W

◆ Isolated LED lamp compartment, CC-CV (constant current – constant voltage) power controller compartment and terminal compartment; Wind-convection heat dissipation structure.

◆ International brand white light LED, reasonable arrangement of multi LED, high lighting efficiency and long service life.

◆ Two types of light distribution: spotlight and floodlight, which can be selected on request.

◆ Low-maintenance due to long service life is up to 100,000 operating hours.

Selection table：
Type /
Ordering code		 Lamp
power(W)		 Weight
(kg)		 Type/
Ordering code		 Lamp
power(W)		 Weight
(kg)		 Type /
Ordering code		 Lamp
power(W)		 Weight
(kg)
HRD95-90-60K 60 9.80 HRD95-90-60D 60 9.50 HRD95-160-120B 120 13.50
HRD95-90-90K 90 9.80 HRD95-90-90D 90 9.50 HRD95-160-160B 160 13.50
HRD95-160-120K 120 12.70 HRD95-160-120D 120 11.75 HRD95-240-200B 200 26.60
HRD95-160-160K 160 12.70 HRD95-160-160D 160 11.75 HRD95-240-240B 240 26.60
HRD95-240-200K 200 27.50 HRD95-90-60L 60 9.30 HRD95-90-60X 60 9.20
HRD95-240-240K 240 27.50 HRD95-90-90L 90 9.30 HRD95-90-90X 90 9.20
HRD95-90-60G 60 10.75 HRD95-160-120L 120 12.00 HRD95-160-120X 120 11.75
HRD95-90-90G 90 10.75 HRD95-160-160L 160 12.00 HRD95-160-160X 160 11.75
HRD95-160-120G 120 13.05 HRD95-90-60B 60 11.00 HRD95-240-200X 200 24.80
HRD95-160-160G 160 13.05 HRD95-90-90B 90 11.00 HRD95-240-240X 240 24.80
Note:1.The product is supplied according to “Type/Ordering code”in the table with mounting accessories.
2.Two types of light distribution:spotlight and floodlight.The light fitings are suppliedwithout lens.Lighting distribution is
of floodlight.If required,please specify when ordering.
