JQ-DH Mechanical Shock Absorber
Description
JQ-DH Mechanical Shock Absorber
JQ-DH shock absorber is an absorbing tool acting as a vertical absorbing function when drilling with cone bits or abrasive coring bits. It can absorb or slow down vertical shocking and impact a load of drill stem when drilling, thereby keep normal drilling pressure, prolong working life of drill bit, protect drilling tools and surface equipment, decrease drilling cost, increase drilling efficiency.
JQ-DH uses butterfly spring as an elastic element, it is different from hydraulic shock absorber using silicon oil and other fluid as working medium, its working properly doesn’t be affected by working environment, this mechanical type shock absorber is a new R&D tool made by our factory and a foreign company, it has the advantages of simple structure, reliable working, convenient operation and maintenance, good absorbing effect, long working life, and high property, it’s one of the most widely used drilling tools oversea.
| ype | OD (mm/inch) |
ID (mm/inch) |
Connection (API) |
Max.upward jarring force (KN) |
Ma.downward jarring force (KN) |
overall length (mm/inch) |
|---|---|---|---|---|---|---|
| BZ121 | 121(4-3/4) | 50.8(2) | NC38 | 450 | 230 | 6356(250) |
| BZ159 | 159(6-1/4) | 57.2(2-1/4) | NC50 | 630 | 360 | 7265(286) |
| BZ165 | 165(6-1/2) | 57.2(2-1/4) | NC50 | 630 | 360 | 7265(286) |
| BZ196 | 196(7-3/4) | 71.4(2-13/16) | 6-5/8REG | 820 | 460 | 7062(287) |
| BZ203 | 203(8) | 71.4(2-13/16) | 6-5/8REG | 820 | 460 | 7062(287) |
